KURZ Precise Cartilage Knife Set – for cartilage cutting in even thicknesses

KURZ PRECISE CARTILAGE KNIFE

Functional unit with which cartilage slices can be made easily, quickly and in a standardized fashion
Stable, single-use sterile blades with template for graft size determination
Distance plates (0.1/0.2/0.3 mm) make it possible to produce cartilage slices in thicknesses ranging from 0.1 mm to 0.7 mm
KURZ Precise Cartilage Knife in instrument tray
Material: Sterilizable instrument quality stainless steel
Each blade is individually packed sterile in boxes of 10 each

Product Information

FOR CUTTING CONSISTENTLY THIN CARTILAGE SLICES AS FINE AS 0.1 MM

The KURZ Precise Cartilage Knife facilitates the cutting of consistently thin cartilage slices, as required for occluding tympanic membrane defects, covering tympanoplasty prostheses, or for reconstruction of the posterior auditory canal wall. It is equally suitable for cutting tragal and conchal cartilage conserving specimen material.

The cutting block, blade holder, and blade of the KURZ Precise Cartilage Knife make up a functional unit with which 0.7 mm cartilage slices can be made easily, quickly and in a standardized fashion. Distance plates (0.1/0.2/0.3 mm) make it possible to produce cartilage slices in thicknesses ranging from 0.1 mm to 0.7 mm. The blades are particularly sturdy and contain one oval and one circular template imprinted on each blade face. The latter indicates the minimum size of graft for covering a KURZ tympanoplasty prosthesis.

Benefits

Facilitates the cutting of consistently thin cartilage slices – easily, quickly and in a standardized fashion
Equally suitable for cutting tragal and conchal cartilage conserving specimen material

Ordering Information

Ordering Information - KURZ Precise Cartilage Knife

ITEM

REF

KURZ Precise Cartilage Knife Set

(blade holder, cutting block, distance plates) incl. Instrument Tray

blades sterile single packed are available under REF 8000 140

8000 155

Distance Plate for Precise 1mm

(for compression of fascia)

8000 105

Ordering Information - Supplies

Supplies	REF
Blades sterile single packed, 10 pieces	8000 140

Ordering Information - Replacement Parts

Replacement parts	REF
1 Set of Distance Plates (0.1/0.2/0.3 mm)	8000 102
KURZ Precise Blade Holder incl. Knurled Screw M3, St. 1.4305	8000 103
Instrument Tray KURZ Precise	8000 177
Knurled Scew M3, St. 1.4305	8000 190
Nut Precise Cutting Block M6	8000 191
KURZ Precise Cutting Block incl. Nut Precise Cutting Block M6	8000 110
Instrument Tray KURZ Precise incl. Plate POM+Tray stainless steel	8000 144

Prescription Devices Caution:

United States Federal Law restricts devices identified herein to sale by or on the order of a physician.
These pages do not replace nor do they set forth the complete contents of the “Instructions for Use” for the products shown here, and are not substitute for reviewing and understanding that important information. Therefore, before using any products included here, please review the entire contents of the respective “Instructions for Use” information.
Because of registration the product is currently not available in all countries.

Literature

Cartilage Plate Tympanoplasty

Beutner D., Huettenbrink K.-B., Stumpf R., Beleites T.,
Zahnert T., Luers J.-C., Helmstaedter V.

Published: Otology & Neurotology, 2009

Literature

Acoustic properties of different cartilage reconstruction
techniques of the tympanic membrane

Mürbe D., Zahnert T., Bornitz M., Hüttenbrink K.-B.

Published: Laryngoscope 2002 Oct; 112(10):1769-76.

Literature

Experimental investigations of the use of cartilage in
tympanic membrane reconstruction

Zahnert T., Hüttenbrink K.-B., Mürbe D., Bomitz M.

Published: Am J Otol. 2000 May;21(3):322-8.

Literature

Type III tympanoplasty applying the palisade cartilage
technique: a study of 61 cases

Neumann A., Schultz-Coulon H.-J., Jahnke K.

Published: Otol Neurotol. 2003 Jan;24(1):33-7.

DMS 0004023_Rev.02
